• Up to 2160P high resolution, with horizontal 118°wide angle, diagonal 143°.
• F1.75 super large aperture offer a perfect night image.
• Support built-in MIC and speaker for audio in and out.
• Built-in WIFI module and WIFI AP function supported.
• Built-in G-Sensor module, support video recording linkage at car crash or strong vibration. (Linkage video record can be configured be no-overwritten )
• Support GPS module with speed display and route tracking playback.
• TF card for video recording, 32GB to 256GB (Overwriting supported)
• Phone App: live view, record playback and parameter configuration.
• Voice recognition supported : Snapshot, Recording on, Recording off.
• ADAS supported: “Traffic light turn green”, “Speed limit recognition”, “Front car start remind”.
• Easy installation and user friendly, plug and play. (Automatically recording after power on )
• Low power consumption and high performance.

Camera

• Image SensorSC8238
• Angle Adjustmentadjustable up and down, left and right angles 30°
• Power-off Memoryyes

Lens

• Lens Type2D 5G
• ApertureF1.75

Wi-Fi

• Frequency Range5725-5875MHZ
• Channel Bandwidth40MHz

Mobile Communication

• Transmission Rate40Mbps


• Wide Dynamic Range (WDR)YES
• Image EnhancementYES

Interface

• Built-in MicrophoneYES
• Built-in SpeakerYES
• Extension InterfaceMini USB(4G)

General

• GPSNO
• WiFi2.4G/5G
• Wi-Fi SupportYES
• Resolution

  2160P(3840×2160)@25fps+1080P@30fps

  1440P(2560×1440)@30fps+1080P@30fps

  1080P(1920×1080)@30fps+1080P@30fps

• Max. Resolution2160P(3840×2160)@30fps
• Video CompressionH.265
• FOV118° (D), 143° (H)
• Camera Dimension

  104 mm × 49 mm × 39 mm

  (4.1ʺ × 1.9ʺ × 1.5ʺ)

• Camera WeightApprox. 118 g (0.26 lb)
• Software ResetYES
• Online UpgradeYES
• Power Consumption and CurrentApprox. 3.5 W
• Power Supply5 V DC, 2 A
• StorageTF card, 32GB to 256GB
• Working temperature-20 °C to 70 °C (-4 °F to 158 °F)
• Working humidity95%(Max)
• Power InterfaceMicro
• OSDDisplay time, date, etc.
• Image formatJPEG
• Local StorageNO
• ADASYES
• Speech recognitionYES
