• 2.4-inch LCD screen
• Multiple authentication methods, including fingerprint, card (M1 card), and PIN, etc.
• Max. 3000 cards, 3000 fingerprints and 100,000 events
• Supports ISAPI and ISUP 5.0 protocols
• Configuration via the PC web client and mobile web client
• Supports wired network and Wi-Fi (AP mode)
• Supports wiring with secure door control unit or card reader via RS-485
• Supports power supply by battery in the bracket
• Supports access control and local time and attendance function

System

• Operating systemLinux

Display

• Screen size2.4 inch
• TypeLCD
• Resolution320 × 240

Audio

• Audio outputBuilt-in buzzer

Network

• Wired networkSupport
• Wi-FiSupport, 2.4 G, 802.11b/g/n

Interface

• Network interface1 RJ-45, 10/100 M self-adaptive
• Lock control1
• Exit button1
• Door contact input1
• TAMPER1
• RS-4851 RS-485 (Half duplex, HIKVISION)
• Wiegand1 Wiegand (W26, W34)
• USB1

Capacity

• Fingerprint capacity3000
• Card capacity3000
• Event capacity100,000

Authentication

• Card typeM1 card
• Fingerprint moduleOptical fingerprint module
• Fingerprint comparing mode1:1 and 1:N

General

• Power supply

  12 VDC

  Supports power supply by battery in the bracket

• Power consumption≤ 6 W
• Working temperature-10 °C to 55 °C (14 °F to 131 °F)
• Working humidity0 to 90% (No condensing)
• LanguageEnglish, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese, Portuguese (Brazil), Korean, Japanese
• KeypadSupport
