• PIR Detection Range: 12m / 85.9°
• Glass Break Range: 8m / 120°
• Up to 30KG pet immunity
• Fully remote configurable through App
• Multiple enrollment method and easy installation design
• Easy replaceable battery with PCB protected

Detection Performance

• Detection methodPassive Infrared;Acoustic Sensor
• Detection range12m
• Detection angle85.9°
• Detection zones52
• Detectable speed0.3～2m/s
• Pet immunity30 kg
• PIR sensitivityAuto,High,Pet
• White light filter6500lux
• Glass break range8m
• Glass typeFloat;Plate;Tampered;Wired;Laminated Leaded;Double Glazing
• Glass break sensitivity0 to 2 meters: Level 2;2.1 to 4 meters: Level 3;4.1 to 6.4 meters: Level 4;6.6 to 7.1 meters: Level 5;7.2 to 8 meters: Level 6;Additional: Level / 8 is for more sensitive (Not compliance to EN50131-2-7-1)
• Glass thickness2.4mm to 6.4mm
• Digital temperature compensationSupport
• Glass size0.3m x 0.3m to 3m x 3m
• Creep zone protectionSupport

Feature

• Digital processingSupport
• Sealed opticsSupport
• Tamper protectionFront;Rear
• Environment temperature IndicatorSupport
• Signal strength indicatorSupport

Interface

• Power switchPower Up Enrolling
• LED indicatorGreen(PIR),Red(BG),Blue(alarm)

Transmission

• Transmission technologyTri-X Wireless
• Transmission methodTwo-Way RF Wireless
• Transmission frequency433MHz
• Transmission securitySupport
• Transmission range(free space)1 km
• Frequency hoppingSupport
• Enrolling methodPower up;Remote ID;QR Code

Electrical Characteristics

• Standard battery life

  Up to 4 years (standby time)

• Power supplyBattery Powered
• Battery typeCR123A × 2
• Typical voltage3V

General

• Operation temperature-10 °C to 55 °C (14 °F to 131 °F)
• Storage temperature-20 °C to 60 °C (-4 °F to 140 °F)
• Operation humidity10% to 90%
• Dimension(W×H×D)65.5mm×103mm×48.5mm
• 134g
• Mounting height1.8 to 2.4m
• Mounting methodWall
• Application scenarioIndoor
• BracketOptional Wall & Ceiling Accessory
