• Support Wifi, convenient setting up and no wiring required
• Support web configuration
• Aluminum alloy, Nice industry design, IP65, IK08, 3 indicator integrated
• Internal Mifare card reader, 4-ch Indoor station access control
• Noise suppression and echo cancellation
• 2MP HD Camera with IR supplement
• Standard PoE/12 VDC

Display parameters

• Size/
• Operation method/
• Type/
• Video parameters
• Supplement light

  IR supplement

• Lens1
• FOVHorizontal: 129° Vertical: 75°
• Pixel

  Main stream : 1920 × 1080

  Sub stream : 720 × 480

Audio parameters

• Audio qualityNoise suppression and echo cancellation
• Network parameters
• Communication protocol

  TCP/IP, RSTP

• Wired network10/100 Mbps self-adaptive Ethernet
• Wi-Fi/
• Bluetooth/

Device interfaces

• Network interface1
• Exit button2
• Lock control2
• Door contact input2
• Power interface1

General

• Button4
• Installation

  Surface Mounting

• Indicator3
• 385g
• Protective levelIP65, IK08
• Power supply method

  IEEE802.3af, standard PoE

  12 VDC

• Working temperature-40° C to +55° C(-40° F to 131° F)
• Working humidity

  10% to 95%

• Dimensions174 mm × 91 mm × 29 mm
• Battery/
• Application environmentOutdoor
• Power consumption

  ＜ 10 W
