• 2.4-inch LCD screen, 2 MP lens
• Multiple authentication methods, including face, fingerprint, card (EM card), and PIN, etc.
• Max. 500 faces, 3000 cards, 3000 fingerprints and 150,000 events
• Face recognition duration < 0.2 s/User
• Supports ISAPI and ISUP 5.0 protocols
• Configuration via the PC web client and mobile web client
• Supports wired network and Wi-Fi (AP mode)
• Supports wiring with secure door control unit or card reader via RS-485
• Supports power supply by battery in the bracket
• Supports access control and local time and attendance function

System

• Operating systemLinux

Display

• Screen size2.4 inch
• TypeLCD
• Resolution320 × 240

Video

• Lens1
• Resolution2 MP (video stream: 720P)
• Video standardPAL (Default) and NTSC

Audio

• Audio outputBuilt-in buzzer

Network

• Wired networkSupport
• Wi-FiSupport, 2.4 G, 802.11b/g/n

Interface

• Network interface1 RJ-45, 10/100 M self-adaptive
• Lock control1
• Exit button1
• Door contact input1
• TAMPER1
• RS-4851 RS-485 (Half duplex, HIKVISION)
• USB1

Capacity

• Face capacity500
• Fingerprint capacity3000
• Card capacity3000
• Event capacity150,000

Authentication

• Face recognition distance0.3 m ~ 1.5 m
• Face recognition accuracy rate> 99%
• Face recognition duration< 0.2 s
• Card typeEM card

General

• Power supply

  12 VDC

  Supports power supply by battery in the bracket

• Power consumption≤ 6 W
• Working temperature-10 °C to 55 °C (14 °F to 131 °F)
• Working humidity0 to 90% (No condensing)
• LanguageEnglish, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese, Portuguese (Brazil), Korean, Japanese
• KeypadSupport

Function

• Face anti-spoofingSupport
• Face recognitionSupport
