• 2.4-inch LCD screen, 2 MP lens
• Multiple authentication methods, including face, fingerprint, card, and PIN, etc.
• Supports M1 card
• Max. 500 faces, 1,000 cards, 1,000 fingerprints and 100,000 events
• Face recognition duration < 0.2 s/User
• Supports ISAPI and ISUP 5.0 protocols
• Configuration via the web client
• Supports power supply by battery in the bracket
• Supports access control and local time and attendance function

System

• Operating systemLinux

Display

• Screen size2.4 inch
• TypeLCD
• Resolution320 × 240

Video

• Lens1
• Video compression standardPAL (Default) and NTSC
• Resolution2 MP (video stream: 720P)

Audio

• Audio outputBuilt-in buzzer

Network

• Wired networkSupport
• Wi-FiSupport, 2.4 G, 802.11b/g/n

Interface

• Network interface1 RJ-45, 10/100 M self-adaptive
• Lock control1
• Exit button1
• Door contact input1
• TAMPER1
• USB1

Capacity

• Face capacity500
• Fingerprint capacity1,000
• Card capacity1,000
• Event capacity100,000

Authentication

• Face recognition distance0.3 m ~ 1.5 m
• Face recognition accuracy rate> 99%
• Face recognition duration< 0.2 s
• Card typeM1 card

General

• Built-in access controllerSupport
• Power supply

  12 VDC

  Supports power supply by battery in the bracket

• Power consumption≤ 6 W
• Working temperature-10 °C to 55 °C (14 °F to 131 °F)
• Working humidity0 to 90% (No condensing)
• LanguageEnglish, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese, Portuguese (Brazil), Korean, Japanese

Function

• Face anti-spoofingSupport
