• Up to 8 channel IP cameras can be connected
• Supports decoding H.265+/H.265/H.264+/H.264 video formats
• Up to 4 MP high-definition live view, storage and playback
• Up to 4-ch @ 1080p decoding capacity
• 1 HDD for continuous video recording
• Easy to install through automatic wireless connection
• Easy to manage through Hik-Connect app

Video and Audio

• IP Video Input8-ch
• HDMI Output1-ch, resolution: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
• VGA OutputHDMI,VGA
• Incoming Bandwidth50/40 Mbps
• Audio Output1-ch, RCA (linear, 1 KΩ)

Decoding

• Decoding FormatH.265+,H.265,H.264+,H.264
• Decoding Capability4-ch@1080p / 1-ch@4 MP
• Synchronous playback8-ch
• Recording Resolution4 M/3 M/1080p/1.3 M/720p

Network

• Network Interface1, RJ45 10/100M Ethernet interface

PoE

• InterfaceN/A

Wireless Parameter

• Frequency Band2.4 GHz
• Antenna Structure2 × 2MIMO
• Transmission Speed144 Mbps
• Transmission StandardIEEE 802.11b/g/n

RAID

• RAID Type No

Auxiliary Interface

• SATA1
• CapacityUp to 6 TB capacity for each disk
• USB InterfaceRear panel: 2 × USB 2.0

General

• Power Supply12 VDC
• Consumption≤ 12 W
• Working Temperature-10 °C to +55 °C (14 °F to 131 °F)
• Working Humidity10% to 90%
• Dimension (W × D × H)260 × 246 × 48 mm (10.2" × 9.7" × 1.9")
• ≤ 1 kg (2.2 lb)
