• High quality imaging with 3K, 2960 × 1665 resolution
• 2.8 mm, 3.6 mm fixed focal lens
• Up to 20 m white light and 25 m IR distance for bright night imaging
• Smart-Hybrid Light, optimize your security with flexible lighting options
• High quality audio with audio over coaxial cable, built-in mic, and built-in speaker
• Provide real-time communication via built-in two-way audio
• Water and dust resistant (IP67)

Camera

• Image Sensor3K CMOS
• Max. Resolution2960 (H) × 1665 (V)
• Min. Illumination0.01 Lux @ (F1.6, AGC ON), 0 Lux with IR
• Shutter TimePAL: 1/12.5 s to 1/50,000 s,NTSC: 1/15 s to 1/50,000 s
• Day & NightICR
• Angle AdjustmentPan: 0° to 360°,Tilt: 0° to 90°,Rotate: 0° to 360°
• Signal SystemPAL/NTSC

Lens

• Lens Type2.8 mm, 3.6 mm fixed lens
• Focal Length & FOV

  2.8 mm, horizontal FOV: 105°, vertical FOV: 62°, diagonal FOV: 131°;

  3.6 mm, horizontal FOV: 80°, vertical FOV: 48°, diagonal FOV: 112°

• Lens MountM12

Microphone

• Pickup DistanceIn a radius of up to 5 m
• Amount1

Speaker

• Rated Power2 W
• Speaker RangeIn a radius of up to 5 m

Illuminator

• Supplement Light TypeSmart,IR,White Light
• Supplement Light RangeIR: Up to 25 m,White Light: Up to 20 m


• Image Settings



  Anti-banding,

  Brightness,

  Sharpness,

  Smart IR

• Frame RateTVI: 3K @10 fps/12.5 fps/20 fps/25 fps, 4 MP @25 fps/30 fps, 1080P @25 fps/30 fps
• Day/Night ModeAuto/Color
• Wide Dynamic Range (WDR)Digital WDR
• Image Enhancement

  DWDR,

  BLC,

  HLC,

  Global,

  HLS

• Noise Reduction2D DNR
• White Balance

  Auto,

  Manual

Audio

• Audio FunctionEcho Cancellation, AI Noise Reduction, Automatic Gain Control

Interface

• Video Output1 HD analog output

General

• Power

  12 VDC ± 25%, max. 4.8 W,

  *You are recommended to use one power adapter to supply the power for one camera.

• MaterialPlastic
• Dimension179 mm × 66 mm × 69.1 mm (7.05" × 2.6" × 2.72")
• Approx. 245 g (0.92 lb.)
• Operating Condition-40 °C to 60 °C (-40 °F to 140 °F). Humidity 90% or less (non-condensing)
• CommunicationHIKVISION-C
• LanguageEnglish

Approval

• ProtectionIP67
