• High quality imaging with 2 MP, 1920 × 1080 resolution
• 24/7 color imaging with F1.0 aperture
• Smart-Hybrid light, optimize your security with flexible lighting options
• Clear imaging against strong back light due to 130 dB true WDR technology
• 3D DNR technology delivers clean and sharp images
• Up to 40 m white light distance for bright night imaging
• Up to 40 m IR distance for bright night imaging
• Built-in mic, high quality audio with audio over coaxial cable
• Provide real-time security via built-in two-way audio
• Water and dust resistant (IP67)

Camera

• Image Sensor2 MP CMOS
• Max. Resolution1920 (H) × 1080 (V)
• Min. Illumination0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
• Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
• Day & NightICR
• Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 75°, Rotate: 0° to 360°
• Signal SystemPAL/NTSC
• Slow ShutterMax. 16 times

Lens

• Lens Type2.8 mm, 3.6 mm fixed focal lens
• Focal Length & FOV

  2.8 mm, horizontal FOV: 105°, vertical FOV: 56°, diagonal FOV: 126°

  3.6 mm, horizontal FOV: 84°, vertical FOV: 46°, diagonal FOV: 98°

• Lens MountM12

Microphone

• Pickup DistanceIn a radius of up to 5 m
• Amount1

Speaker

• Rated Power2 W
• Speaker RangeIn a radius of up to 5 m

Functions

• Audio FunctionEcho Cancellation, AI Noise Reduction, Automatic Gain Control

Illuminator

• Supplement Light Type

  IR,

  White Light

• Supplement Light Range

  IR: Up to 40 m,

  White Light: Up to 40 m


• Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
• Image SettingsBrightness, Contrast, Sharpness, Anti-banding, AGC
• Frame RateTVI: 1080p @25 fps/30 fps
• Day/Night ModeAuto/Color
• Wide Dynamic Range (WDR)≥120 dB
• Image Enhancement

  WDR,

  BLC,

  HLC,

  Global,

  HLS

• Noise Reduction3D DNR
• White Balance

  Auto,

  Manual

Interface

• Video Output1 HD analog output

Event

• Light AlarmFlashing Light Alarm (Red and Blue)
• Audible AlarmYes

General

• MaterialMain body: Metal, Enclosure: Plastic
• DimensionØ110 mm × 102.7 mm (Ø4.33" × 4.04")
• Approx. 395 g (0.87 lb.)
• Operating Condition-40 °C to 60 °C (-40 °F to 140 °F). Humidity 90% or less (non-condensing)
• CommunicationHIKVISION-C
• LanguageEnglish
• Power

  12 VDC ± 25%, max. 11.1 W

  *You are recommended to use one power adapter to supply the power for one camera. If a high-impedance cable is used (such as the 18 m extension cable in the kit package), a 15 VDC adapter is required.

Approval

• ProtectionIP67
