• High quality imaging with 3K, 2960 × 1665 resolution
• 24/7 color imaging with F1.0 aperture
• Smart-Hybrid light, optimize your security with flexible lighting options
• Clear imaging against strong back light due to 130 dB true WDR technology
• 3D DNR technology delivers clean and sharp images
• Up to 20 m white light and 30 m IR distance for bright night imaging
• High quality audio with audio over coaxial cable, built-in mic
• Water and dust resistant (IP67)

Camera

• Image Sensor3K CMOS
• Max. Resolution2960 (H) × 1665 (V)
• Min. Illumination0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
• Shutter TimePAL: 1/25 s to 1/50,000 s,NTSC: 1/30 s to 1/50,000 s
• Day & NightICR
• Angle AdjustmentPan: 0° to 360°,Tilt: 0° to 90°, Rotation: 0° to 360°
• Signal SystemPAL/NTSC
• Slow ShutterMax. 16 times

Lens

• Lens Type2.8 mm, 3.6 mm fixed focal lens
• Focal Length & FOV

  2.8 mm, horizontal FOV: 112°, vertical FOV: 60°, diagonal FOV: 140°

  3.6 mm, horizontal FOV: 90°, vertical FOV: 49°, diagonal FOV: 105°

• Lens MountM12

Microphone

• Pickup DistanceIn a radius of up to 5 m
• Amount1

Illuminator

• Supplement Light TypeSmart,IR,White Light
• Supplement Light RangeIR: Up to 30 m,White Light: Up to 20 m


• Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
• Image SettingsSaturation,Brightness,Contrast,Sharpness,Anti-banding,AGC
• Frame RateTVI: 3K @20 fps/25 fps, 4 MP @25 fps/30 fps, 1080p @25 fps/30 fps
• Day/Night ModeAuto/Color
• Wide Dynamic Range (WDR)≥130 dB
• Image EnhancementWDR,BLC,HLC,Global
• Privacy Mask4 programmable polygon privacy masks
• Noise Reduction3D DNR
• White BalanceAuto,Manual

Interface

• Video Output1 HD analog output

General

• Power12 VDC ± 25%, max. 6.1 W,*You are recommended to use one power adapter to supply the power for one camera.,If a high-impedance cable is used (such as the 18 m extension cable in the kit package), a 15 VDC adapter is required.
• MaterialMetal
• Dimension179 mm × 66 mm × 69.1 mm (7.05" × 2.6" × 2.72")
• Approx. 430 g (0.95 lb.)
• Operating Condition-40 °C to 60 °C (-40 °F to 140 °F). Humidity 90% or less (non-condensing)
• CommunicationHIKVISION-C
• LanguageEnglish

Approval

• ProtectionIP67
