• Stable electrical performance, compliant with ANSI/TIA-568.2-D, IEC61156, ISO/IEC11801.
• Sheath with strong mechanical properties, and high tensile and compressive strength, reducing damage during the project.
• Excellent performance in the Fluke 90-meter permanent link test while working continuously at 50°C high temperature.
• Excellent performance in the Fluke 100-meter channel test while being continuously loaded with 57 V/1 A DC power (PoE).
• Solid-Bare Copper conductor with less resistance, and better electrical properties and transmission performance.
• Compliant with RoHS 2.0.

General

• CategoryCat 6
• StructureU/UTP
• Fire ResistanceCPR Fca
• Usage ScenarioIndoor

Sheath

• Sheath Material PVC
• Sheath Color Grey

Conduct

• Conductor MaterialSolid - Bare Copper
• Conductor Diameter 0.50 ± 0.01 mm 24AWG

Insulation

• Insulation Diameter 0.88 ± 0.05 mm

Structure

• Length 90m
• Rip Cord Yes
• Separator Yes
