• High quality imaging with 2K, 2304 × 1296 resolution
• Smart-Hybrid Light,optimize your security with flexible lighting options
• Up to 20 m IR distance for bright night imaging
• Up to 20 m white light distance for bright night imaging
• High quality audio with audio over coaxial cable, built-in mic
• One port for four switchable signals (TVI/AHD/CVI/CVBS）

Camera

• Image Sensor2K CMOS
• Max. Resolution2304 (H) × 1296 (V)
• Min. Illumination0.01 Lux @ (F1.6, AGC ON), 0 Lux with IR
• Shutter TimePAL: 1/25 s to 1/50, 000 s; NTSC: 1/30 s to 1/50, 000 s
• Day & NightICR
• Angle AdjustmentPan: 0 to 360°, Tilt: 0 to 75°, Rotation: 0 to 360°
• Signal SystemPAL/NTSC

Lens

• Lens Type2.8 mm, 3.6 mm fixed focal lens
• Focal Length & FOV

  2.8 mm, horizontal FOV: 105°, vertical FOV: 60°, diagonal FOV: 129°

  3.6 mm, horizontal FOV: 89°, vertical FOV: 47°, diagonal FOV: 107°

• Lens MountM12

Microphone

• Pickup DistanceIn a radius of up to 5 m
• Amount1

Illuminator

• Supplement Light Range

  IR : Up to 20 m

  White Light : Up to 20 m

• Supplement Light TypeSmart,IR,White Light


• Image SettingsBrightness, Sharpness, Smart IR
• Frame Rate

  TVI: 2K @20fps, 1080P @25fps/30fps

  AHD: 1080P @25fps/30fps

  CVI: 1080P @25fps/30fps

  CVBS: PAL/NTSC

• Wide Dynamic Range (WDR)Digital WDR
• Image EnhancementDWDR/BLC/HLC/Global
• White BalanceAuto/Manual
• AGCYes
• Day/Night ModeAuto/Color

Interface

• Video OutputSwitchable TVI/AHD/CVI/CVBS

General

• Power

  12 VDC ± 25%, max. 3.3 W,

  *You are recommended to use one power adapter to supply the power for one camera.

• MaterialPlastic
• Dimension84.6 mm × Ø85.02 mm (3.33" × Ø3.35")
• Approx. 155 g (0.34 lb.)
• Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensing)
• CommunicationHIKVISION-C
• Language English
