• Ultra-thin device body with ultra-thin border for 3 sides.
• 8 bit LVDS HD (1920 × 1080) display.
• 178° ultra-wide view screen.
• 3D noise reduction.
• Low blue light design for eye care.
• Dual interface of HDMI and VGA.
• Support VESA wall mount.
• Built-in speaker for audio input.

Display

• Screen Size23.8 inch
• Active Display Area527.04 mm (H) × 296.46 mm (V)
• Resolution1920 × 1080
• BacklightE-LED
• Pixel Pitch0.0915 (H) mm × 0.2745 (V) mm
• Brightness250 cd/m²
• Viewing Angle178° (H) / 178° (V)
• Color Depth8 bit
• Contrast Ratio4000 : 1
• Response Time6.5 ms (typ)
• Refresh RateMax. 75Hz , Typ. 60 Hz
• HazeHaze 25%, 3H
• Reliability7 × 24 H
• Color Gamut72% NTSC

Interface

• Video & Audio InputHDMI 1.4 × 1, VGA × 1，BNC（CVBS） × 1，AUDIO IN × 1
• Video & Audio OutputSpeaker (2W 8Ω) × 2
• Data Transmission InterfaceUSB 2.0 (support program upgrade and USB online playback) × 1

Power

• Power SupplyAC 100-240V～, 50/60Hz, 0.5A Max
• Power Consumption≤ 25W
• Standby Consumption≤ 0.5 W

Working Environment

• Working Temperature0℃ to 40 ℃ (32 ℉ to 104 ℉)
• Working Humidity20% ~ 90% RH (Non-Condensing)
• Storage Temperature-20 ℃ to 60 ℃ (-4 ℉ to 140 ℉)
• Storage Humidity5%~90% RH (Non-Condensing)

General

• Casing MaterialPlastic
• VESA75 mm × 75 mm (4-M4 × 6 mm)
• Bezel Width1.75 mm (top/left/right), 23.55 mm (bottom)
• Product Dimensions (W × H × D)

  without stand：539.1 (W) mm × 327.04 (H) mm × 41.78 (D) mm（21.22″ × 12.88″ × 1.64″）

  with stand：539.1 (W) mm × 433.2 (H) mm × 209.99 (D) mm（21.22″ × 17.06″ × 8.27″）

• Package Dimensions (W × H × D)650 (W) mm × 475 (H) mm × 135 (D) mm（25.59″ × 18.7″ × 5.31″）
• Net Weight3.32 ± 0.5 kg
