• Up to 8-ch IP camera inputs
• H.265+/H.265/H.264+/H.264 video formats
• Up to 1-ch @ 8MP or 5-ch @ 1080P decoding capacity
• Up to 80 Mbps incoming bandwidth

Motion Detection 2.0

• Human/Vehicle Analysis4

Video and Audio

• IP Video Input8-ch
• HDMI Output1-ch, 4K (4096 x 2160)/30 Hz, 4K (3840 x 2160)/30 Hz, 2K (2560 x 1440)/60 Hz, 1920 x 1080/60 Hz, 1600 x 1200/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz
• VGA Output1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
• Video Output ModeHDMI/VGA simultaneous output
• Incoming Bandwidth80 Mbps
• Outgoing Bandwidth80 Mbps
• Audio Output1-ch, RCA (Linear, 1 KΩ)
• Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 k Ω)

Decoding

• Decoding FormatH.265+,H.265,H.264+,H.264
• Decoding Capability1-ch@8 MP (30 fps)/5-ch@1080p (30 fps)
• Synchronous playback8-ch
• Recording Resolution8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF

Network

• Network ProtocolTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
• Network Interface1, RJ-45 10/100 Mbps self-adaptive Ethernet interface

PoE

• Interface8, RJ-45 10/100 Mbps self-adaptive Ethernet interface
• Power≤ 80W
• StandardIEEE 802.3 af/at

Auxiliary Interface

• SATA2 SATA interfaces
• CapacityUp to 8TB capacity for each disk
• USB Interface2 × USB 2.0

General

• Power Supply48V| ,2.5A MAX
• Consumption≤ 15W
• Working Temperature-10 to +55º C (+14 to +131º F)
• Working Humidity10 to 90 %
• Chassis1U chassis
• Dimension (W × D × H)385 × 315 × 52 mm (15.2"× 12.4" × 2.0")
• ≤ 2.6 kg (5.7 lb)
