• High quality imaging with 2 MP, 1920 × 1080 resolution
• 24/7 color imaging with F1.0 aperture
• Smart-Hybrid Light, optimize your security with flexible lighting options
• 3D DNR technology delivers clean and sharp images
• Up to 20 m white light and 30 m IR distance for bright night imaging
• Active strobe light and audio alarm to warn intruders off
• Built-in mic and built-in speaker，high quality audio with audio over coaxial cable
• Provide real-time communication via built-in two-way audio
• Water and dust resistant (IP67)

Camera

• Image Sensor2 MP CMOS
• Max. Resolution1920 (H) × 1080 (V)
• Min. Illumination0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light
• Shutter TimePAL: 1/25 s to 1/50,000 s,NTSC: 1/15 s to 1/50,000 s
• Day & NightICR
• Angle AdjustmentPan: 0° to 360°,Tilt: 0° to 75°,Rotate: 0° to 360°
• Signal SystemPAL/NTSC

Lens

• Lens Type2.8 mm, 3.6 mm fixed lens
• Focal Length & FOV

  2.8 mm, horizontal FOV: 101°, vertical FOV: 55°, diagonal FOV: 122°;

  3.6 mm, horizontal FOV: 84°, vertical FOV: 47°, diagonal FOV: 99°

• Lens MountM12

Microphone

• Pickup DistanceIn a radius of up to 5 m
• Amount1

Speaker

• Rated Power2 W
• Speaker RangeIn a radius of up to 5 m

Illuminator

• Supplement Light TypeSmart,IR,White Light
• Supplement Light RangeIR: Up to 30 m,White Light: Up to 20 m


• Image Settings

  Anti-banding,

  Brightness,

  Sharpness,

  Smart IR

• Frame RateTVI: 1080p @25 fps/30 fps
• Day/Night ModeAuto/Color
• Wide Dynamic Range (WDR)Digital WDR
• Image Enhancement

  DWDR,

  BLC,

  HLC,

  Global

• Noise Reduction3D DNR
• White Balance

  Auto,

  Manual

Audio

• Audio FunctionEcho Cancellation, AI Noise Reduction, Automatic Gain Control

• Interface
• Video Output1 HD analog output
• AlarmFlashing Light Alarm (Red & Blue)

General

• Power

  12 VDC ± 25%, max. 5.9 W,

  *You are recommended to use one power adapter to supply the power for one camera.

• MaterialPlastic
• DimensionØ110 mm × 93 mm (Ø4.3" × 3.7")
• Approx. 275 g (0.6 lb.)
• Operating Condition-40 °C to 60 °C (-40 °F to 140 °F). Humidity 90% or less (non-condensing)
• CommunicationHIKVISION-C
• LanguageEnglish

Approval

• ProtectionIP67
